CLX-04E MTP,MPO Optic Fiber Polishing Machine

1 Set
CLX-04E MTP,MPO Optic Fiber Polishing Machine
Features Gallery Product Description Request A Quote
Type: Fiber Optic Production Machine
Warranty Time: 1 Years
Polishing Capacity: Maximum 24 Ferrules Per Cycle
Input Voltage: 100-240VAC,50/60Hz
Pressure Source: Compressed Air&Motor
Application: Polishing Ferrules Or Connector MT,mini-MT,MPO
High Light:

60Hz MPO Optical Fiber Polisher


Cable Connector Fiber Grinding Machine


MTP MPO Fiber Grinding Machine

Basic Infomation
Place of Origin: Guangdong,China
Brand Name: CLX
Model Number: FPM-MPO
Payment & Shipping Terms
Packaging Details: Wooden case, shockproof packaging with foam
Delivery Time: 7-10 work days
Payment Terms: T/T
Supply Ability: 10 set/week
Product Description

MTP MPO fiber polisher fiber optical cable connector grinding fiber optic polish fiber polishing machine


Place of Origin:ShenZhen,China

Product description:

CLX-04E fiber polishing machine is designed for MTP MPO connector polishing. And it is also used for regular simplex fiber connector polishing, such as SC, FC, ST, LC upc and APC end-face.


1. Programmable system with memory for procedures.
2. Dual MT UPC&Angled PC connector polishing;
3. High volume polishing,more than 24 ferrules per cycle.

5. Excellent endface quality.


Item Index
Power Source
Voltage : Frequency AC 110-120V: 50Hz/60Hz Or AC 220-240V: 50Hz
Power waste 80VA
Drive Units
Big motor (rpm) 15W,Including transmission
Small motor (rpm) 6 W,Including transmission
Fan φ90mm
Operation unit
Control time Set the growth time of 0.1mins ,maximum time is 3min the middle button is power switch, right button is the start switch
Power switch
Timing switch
Pressure unit Centre coil spring
Pressure way
The least grinding ferrule abrasive sheet level grinding by polishing pad and polishing by PC connector 1 - 48 connector
Outer diameter:110mm
Glass pad
Synthetic rubber pad
Polish PC connector Four-step, 1.4 to 2.4 minutes
Polish APC connector Five-step, 3.0 to 5.0 minutes
Dimension W230 × D230 × H350 mm
Weight Weight



1. Are you a factory or a trader?

-we are factory.

2. What is your MOQ?

-MOQ 1 piece.

3. Do you provide sample services?

-Yes, we will provide samples(Samples at prices announced by chuanglixun).

4. How will you ship to me?

-We will spend 4 to 6 days via DHL or FedEx. Properly extended based on order quantity.

5. How do we pay

-Book in advance or multiple payment methods such as T / T and T / L.

6. How long is your product warranty?

-The warranty period is 1 year (the warranty period will provide free repairs, except for consumables). After the warranty period, accessories will continue to be provided and will be charged at cost.

7. Do you provide customized services?

-Yes, we provide customized services, According to customer requirements and description.
