2000N Fiber Patch Cord Tensile Strength Testing Machine LC SC E2000

1 Piece
MOQ
Negotiable
Price
2000N Fiber Patch Cord Tensile Strength Testing Machine LC SC E2000
Features Gallery Product Description Request A Quote
Features
Specifications
Type: Testers &Tools
Product Name: Tensile Force Testing Machine
Connector: LC SC E2000
Moving Distance: 500 Mm
Net Weight: 60 Kg
Size: 45 X 50 X120 Cm
High Light:

2000N Tensile Strength Testing Machine

,

E2000 tensile strength tester

,

E2000 Tensile Strength Testing Machine

Basic Infomation
Place of Origin: Guangdong,China
Brand Name: CLX
Model Number: CLX-2000N
Payment & Shipping Terms
Packaging Details: Shockproof packaging with foam,caton box, or wooden case,61X53X100 cm,50kg
Delivery Time: 5-8 work days
Payment Terms: T/T
Supply Ability: 20 Piece/Week
Product Description

Fiber Optic Patch Cord LC SC E2000 Tensile Force Testing Machine 200kgf (2000N)


Key Features:

Ø Motor controls up and down movement.

Ø English and Chinese interface.

Ø Desktop type and smart dimension

Ø 12 months warranty from factory.

2000N Fiber Patch Cord Tensile Strength Testing Machine LC SC E2000 0


Technical Parameters:

Capacity 200KGF or 2000N
Accuracy ±0.5 %
Users can set the appropriate break down time according to different materials.
Test Speed 50~300 mm/min
Moving distance 500 mm
Test Width 150 mm
Tensile Unit Kg,lb,N
Display mode LCD English display, film touch key
Stopping Mode

Preset upper and lower points,

detect breaking point.

Report output Computer printing
Driving Source Speed-Adjustable motor
AC Power Source AC220V,50/60Hz
Net Weight 60kg
Package size 45*50*120cm

Technical Parameters:

Item Parameter
Model TFTM-2000N
Capacity 2000N
Dimensions 45 x 50 x120 cm
Input Voltage 100-240VAC,50/60Hz



2000N Fiber Patch Cord Tensile Strength Testing Machine LC SC E2000 1
