High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM

1
MOQ
AED 2,728.25-2,861.36
Price
High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM
Features Gallery Product Description Request A Quote
Features
Specifications
Power Supply: 110~220V AC 50Hz/60Hz
Net Weight: 28kg
Machine Size: L 240(mm) X W 240(mm) X H 260(mm)
Relative Humidity: 15%~85%
Work Temperature: 10° ~ 40° Celsius Degrees
Polishing Plate Size: 127mm
Insertion Loss: ≤0.20dB ( Typical)
Return Loss: PC(UPC) ≥55dB, APC ≥60dB
Electric Power: 126 W
Time Settings: 99 Min 99 Sec (Max)
Polishing Rotation Speed: 140RPM
Maximum Polishing Capacity: 48 Pcs For MU And LC Connectors, 36 Pcs For SC, FC, ST
First Pass Yield: 98%～100%
3D Pass Rate: >= 98% (100% Typical, According To IEC)
Radius Of Curvature: 5-25mm (UPC), 5-12mm (APC)
Highlight:

48 pcs MU/LC capacity Optical Fiber Polishing Machine

,

98% first pass yield Fiber Optic Polishing Machine

,

Adjustable speed 140RPM Fiber Patch Cord Polishing Machine
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: chuanglixun
Model Number: CLX-02E, CLX-02E
Payment & Shipping Terms
Product Description
Optical Fiber Polishing Machine
Fiber pigtail polishing quick connector polishing ferrule fiber cable polishing fiber jumper polishing machine
High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM 0
Product Overview
This fiber optical polishing machine is built on international universal standards and extensive hands-on experience. It exceeds GR-326 end face geometry requirements and incorporates advanced four corners compression and new I.P.C. holder technology, delivering industry-leading results. The machine maintains consistent performance whether polishing 1 or 24 connectors, with stable jig installation and compact design. Engineered for volume production and high productivity, it produces excellent connector end face polishing quality while saving materials and reducing polishing costs.
Key Features
  • High-precision fiber optic polishing equipment
  • Quick-change polishing jigs for efficient operation
  • Planet orbit polishing trails with adjustable rotation speed (typically 140RPM)
  • Maximum capacity: 48 pcs for MU and LC connectors, 36 pcs for SC, FC, ST connectors
  • High efficiency with 98%～100% first pass yield for end face quality
  • IPC structure fiber polishing fixture with independent compression for each connector
  • Fiber optic connector polishing 3D pass rate ≥98% (typically 100% according to IEC)
  • APC return loss ≥60dB, PC(UPC) return loss ≥55dB, Insertion loss ≤0.20dB (typical)
  • High-quality stainless steel construction with heat-treatment ensures precision and durability
  • Excellent stability with 8-10 year operational lifetime
High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM 1 High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM 2
Technical Specifications
Parameter Specification
Machine Type CLX-02E
Product Size L 240mm × W 240mm × H 260mm
Net Weight 28 kg
Power Supply 110~230VAC 50Hz/60Hz
Electric Power 126 W
Relative Humidity 15%~85%
Work Temperature 8℃~45℃
O.D. of Rotation Plate 127 mm (5 inch)
Time Settings 99 min 99 sec (Max)
Insertion Loss ≤0.20dB (typical)
Return Loss PC(UPC) ≥55dB, APC ≥60dB
Polishing Performance Results
Fiber End Face Inspection
High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM 3
High-quality end-face polishing with no white spots, no scratches, and clearly visible fiber edges.
Insertion Loss & Return Loss Test Results
High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM 4
Connector Type SM/UPC SM/APC MM/UPC
Insertion Loss ≤0.20dB ≤0.20dB ≤0.50dB
Return Loss ≥55dB ≥60dB ≥30dB
Geometry Test Results
High-Precision Optical Fiber Polishing Machine with 48 pcs MU/LC Capacity 98% First Pass Yield and Adjustable Speed 140RPM 5
Parameter UPC Criterion APC Criterion
Radius of Curvature 5-25mm 5-12mm
Apex Offset 0-50μm 0-50μm
Fiber Height -100~+50μm -100~+50μm
Angle n/a 8.00+/-0.50°
Get a Free Quotation via Us >>> GO
