High Efficiency Anti-Rust Durable 24 Ports FC UPC Fiber Optic Polishing Jig for Precision Connector Polishing
Product Details
| Type: | Fiber Adapter & Connectors | Material: | Hardened Stainless Steel S136 |
|---|---|---|---|
| Dimensions: | 174mmx174mmx5.1mm | Weight: | 1.2kg |
| No. Of Fiber: | 24 | Ferrule Diameter: | 2.5mm |
| Capacity: | 24 Positions | Insertion Loss: | ≤0.20dB |
| Return Loss: | ≥55dB (PC) | End-face: | PC |
| Connector Type: | FC PC | Model: | FC-PC-24 |
| Net Weight: | 1.5 Kgs | Gross Weight: | 2.0 Kgs |
| Suitable Machines: | CLX-02E Polishing Machine, Seikoh Giken SFP-550 Polishing Machine | ||
| Highlight |
High Efficiency Polishing Fixture,Anti-Rust Fiber Optic Polishing Jig,Durable Fiber Polishing Fixture |
||
Product Description
Product Highlights
Silicon Dioxide Fiber Optic Polishing Tools
Japan NTTAT ADS-127 Silicon Dioxide Final Polishing Film Model:ADS-127 Place of Origin:Japan Quick Detail ● Evenly-sprayed particles on coated surface ● Good intensity & flexility, suitable for polishing on different facets ● Suitable for polishing with dry, water or oil medium ● The fiber polishing film is durable polishing rate compared to existing polishing films and offers economical operations Description This product is a silica ADS polishing sheet developed by NTT,
Diamond Polishing Film For Lapping Optical Fiber Patch Cord Cable
Diamond Polishing Film Polishing Paper for Lapping Optical Fiber Patch Cord/Cable Fiber Optic Polishing Paper Features: 1. Uniform dispersion of abrasive particles. 2. Good strength and flexibility. 3. High polishing accuracy. 4. Stable product quality, small difference in batch nails 5. Suitable for polishing with dry, water or oil. Fiber Optic Polishing Film Application: 1. Cutting angle of fiber optic connector, rough grinding, medium grinding, fine grinding 2. Grinding
Blue Fiber Patch Cord Connectors
SC UPC Single-mode simplex 3.0mm fiber optic connector kits Model:SX-SM-SC-UPC-3.0mm Place of Origin:ShenZhen,China Specifications Parameter Unit FC,SC,LC ST,MU MT-RJ,MPO SM MM SM MM SM MM PC UPC APC PC PC UPC PC PC UPC PC Insertion loss dB ≤0.3 ≤0.2 ≤0.3 ≤0.2 ≤0.2 ≤0.2 ≤0.2 ≤0.3 ≤0.2 ≤0.2 Return loss dB ≥45 ≥50 ≥60 ≥30 ≥50 ≥50 ≥30 ≥45 ≥50 ≥35 Operating Wavelength nm 1310,1550 1310,1550 1310,1550 Exchangeability dB ≤0.2 ≤0.2 ≤0.2 Vibration dB ≤0.2 ≤0.2 ≤0.2 Operating
0.9MM Fiber Optic Pigtail Connector , SM MM LC Optical Connector Temperature Control
Optical fiber pigtail optic LC 0.9 connector parts OM4 OM3 SM MM LC 0.9 boot connectorModel:SX-MM-LC-0.9mmPlace of Origin:ShenZhen,ChinaDescriptionProduct NameOptical fiber pigtail optic LC 0.9 Connector PartsModel NumberLC 0.9 fiber optic connectorFiber TypeSM OM1 OM2 OM3 OM4Connector TypeLCInsertion Loss≤0.3dBReturn Loss≥50dBApplicationFTTX,CATV Metro,LANForm of saleOEM/ODMUsePatch cord,PLC splitter,PigtailCustom DesignWelcomeSample Lead Time1 daySample PriceAs per sample
