36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB

1
MOQ
$336.25-365.16
Price
36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB
Features Gallery Product Description Request A Quote
Features
Specifications
Material: Hardened Stainless Steel2316
Connector Type: SC APC Connector
Size: 174*174*26mm
Ferrule Diameter: 2.50mm
Net Weight: 1.5 Kgs
Gross Weight: 2.0 Kgs
No. Of Fiber: 36 Positions
Insertion Loss: ≤0.20dB
Return Loss: ≥60dB (APC)
End-face: APC
Capacity: 36 Positions
Radius Of Curvature: 5-12mm
Apex Offset: 0-50μm
Fiber Height: -100~+50μm
Angle: 8.00+/-0.50°
Highlight:

36 Positions Fiber Optic Polishing Jig

,

Hardened Stainless Steel S2316 Polishing Fixture

,

APC Return Loss ≥60dB Fiber Polishing Fixture
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Chuanglixun
Certification: ce
Model Number: SC-APC-36
Payment & Shipping Terms
Product Description
High Quality SC APC Fiber Optic Connector Polishing Jig 36 With Green
36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB 0
Product Description
This fiber polishing fixture/jig offers high stability and excellent surface quality. Manufactured from high-quality heat-treated steel (hardened steel S2316) for extended service life. The jig can be designed for SC, FC, ST, LC connectors and customized according to customer requirements.
Key Features
  • Designed specifically for SC/APC connectors
  • Easy jig changing with simple, flexible operation
  • High efficiency - polishes up to 36 connectors per cycle with 98%-100% first pass yield
  • IPC structure with independent compression for each connector
  • APC return loss ≥60dB, insertion loss ≤0.20dB (typical)
  • Replaceable accessories for extended service life
Specifications
Model SC-UPC-24 SC-APC-26 SC-APC-36
Brand CLX CLX CLX
Connector Type SC UPC SC APC SC APC
End-face UPC APC APC
Ferrule Diameter 2.5mm 2.5mm 2.5mm
Capacity 24 positions 26 positions 36 positions
Insertion Loss ≤0.20dB ≤0.20dB ≤0.20dB
Return Loss ≥50dB (UPC) ≥60dB (APC) ≥60dB (APC)
Application Polishing assembled SC UPC connectors Polishing assembled SC APC connectors Polishing assembled SC APC connectors
Material Stainless Steel S136
Dimension (L*W*H) 174*174*26 mm
Net Weight / Gross Weight (kg) 1.5 kgs / 2.0 kgs
Suitable machines CLX-02E polishing machine, Seikoh Giken SFP-550 polishing machine, and similar machines
36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB 1 36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB 2
Polishing Effect
1. Polished Connector Ferrule Faces
36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB 3
High-quality end-face polishing with no white spots or scratches. The fiber edge is clearly visible.
2. ILRL Test Result
36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB 4
Connector Type SM/UPC SM/APC MM/UPC
Insertion Loss ≤0.20dB ≤0.20dB ≤0.50dB
Return loss ≥55dB ≥60dB ≥30dB
3. Geometry Test Result
36 Positions SC APC Connector Fiber Optic Polishing Jig with Hardened Stainless Steel S2316 and APC Return Loss ≥60dB 5
NO. Parameters UPC Criterion APC Criterion
1. Radius of Curvature 5-25mm 5-12mm
2. Apex Offset 0-50μm 0-50μm
3. Fiber Height -100~+50μm -100~+50μm
4. Angle n/a 8.00+/-0.50°
