Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100%

1
MOQ
$175-180
Price
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100%
Features Gallery Product Description Request A Quote
Features
Specifications
Net Weight: 0.5kg
Material: Harden Stainless Steel
Dimensions: 110*5mm
No. Of Fiber: 12/16
3D Pass Rate: 100%
Insertion Loss: ≤0.20dB
Return Loss: ≥55dB (PC) ≥60dB (APC)
Connector Type: SC,FC,LC,ST (PC/APC)
Polishing Machine Type: Center Pressure Polish Machine
Number Of Fiber Cores: 16
Radius Of Curvature: 5-25mm (UPC), 5-12mm (APC)
Apex Offset: 0-50μm
Fiber Height: -100~+50μm
Angle: 8.00+/-0.50° (APC)
Interference Pass Rate: ≥98%
Highlight:

Hardened Stainless Steel Polishing Fixture

,

16 Connectors Capacity Fiber Optic Polishing Jig

,

3D Pass Rate 100% LC UPC Polishing Holder
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: Chuanglixun
Model Number: LC/UPC
Payment & Shipping Terms
Product Description
LC UPC Optical Fiber Polishing Fixture
This high-quality fiber polishing fixture is manufactured from heat-treated hardened steel, ensuring exceptional durability and long service life. Designed to accommodate various connector types including SC, FC, ST, LC, and E2000, this fixture can also be customized according to specific customer requirements. With an interference pass rate ≥98%, it delivers outstanding stability and superior surface quality.
Key Features
  • Compatible with center pressure fiber polishing machines for LC/PC (UPC) and LC/APC connectors
  • Independent pressurized system eliminates variations caused by different ferrule lengths
  • High-capacity design holds 16 connectors simultaneously for maximum production efficiency
  • Interchangeable plug system extends fixture lifespan and reduces maintenance costs
  • Premium construction ensures consistent performance and reliability
  • Custom configurations available to meet specific production requirements
Technical Specifications
Model LC/PC, LC/APC
Net Weight 0.5kg
Compatible Connector Types SC, FC, LC, ST (PC/APC)
Polishing Machine Type Center Pressure Polish Machine
Number of Fiber Cores 16
Material Hardened Stainless Steel
Insertion Loss ≤0.20dB
Return Loss ≥55dB (PC), ≥60dB (APC)
Warranty Period 2 Years
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 0 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 1 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 2 Get a Free Quotation via Us >>> GO
Polishing Performance Results
Polished Connector Ferrule Faces
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 3
High-quality end-face polishing with no white spots, no scratches, and clearly visible fiber edges
Insertion Loss & Return Loss Test Results
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 4
Connector Type SM/UPC SM/APC MM/UPC
Insertion Loss ≤0.20dB ≤0.20dB ≤0.50dB
Return Loss ≥55dB ≥60dB ≥30dB
Geometry Test Results
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 5
Parameter UPC Criterion APC Criterion
Radius of Curvature 5-25mm 5-12mm
Apex Offset 0-50μm 0-50μm
Fiber Height -100~+50μm -100~+50μm
Angle n/a 8.00+/-0.50°
Manufacturer Profile
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 6
Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd.
Established in 2010, Shenzhen Chuanglixun Optoelectronic Equipment Co., Ltd. is a leading optical communications equipment company that integrates research and development, production, after-sales service, and technical services. We not only provide high-quality products and comprehensive after-sales support but also offer free technical assistance to our customers. Our team delivers effective solutions for technical challenges encountered in optical fiber connector production.
Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 7 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 8 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 9 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 10 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 11 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 12 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 13 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 14 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 15 Hardened Stainless Steel LC UPC Polishing Fixture with 16 Connectors Capacity and 3D Pass Rate 100% 16 Get a Free Quotation via Us >>> GO
Frequently Asked Questions
  • Are you a factory or a trader?
    We are a factory manufacturer.
  • What is your minimum order quantity?
    MOQ is 1 piece.
  • Do you provide sample services?
    Yes, we provide samples for evaluation.
  • How will you ship to me?
    We ship via DHL or FedEx with delivery in 4-6 days. Shipping time may vary based on order quantity.
  • How do we pay?
    We accept advance booking and multiple payment methods including T/T and T/L.
  • How long is your product warranty?
    The warranty period is 1 year (covering free repairs, excluding consumables). After warranty, we continue to provide accessories at cost.
  • Do you provide customized services?
    Yes, we offer customized services according to customer requirements and specifications.
