Efficient 12 Connectors SC PC Polishing Fixture with Hardened Stainless Steel S136 for 100% 3D Pass Rate

1
MOQ
€185.53-200.75
Price
Efficient 12 Connectors SC PC Polishing Fixture with Hardened Stainless Steel S136 for 100% 3D Pass Rate
Features Gallery Product Description Request A Quote
Features
Specifications
Net Weight: 0.5kg
Material: Harden Stainless Steel
Dimensions: 110*5mm
No. Of Fiber: 12
3D Pass Rate: 100%
Insertion Loss: ≤0.20dB
Return Loss: ≥55dB (PC), ≥60dB (APC)
Steel Type: S2316
Connector Types: SC, FC, ST, LC
Interference Rate: ≥98%
First Pass Yield: 100%
Radius Of Curvature: 5-25mm (UPC), 5-12mm (APC)
Apex Offset: 0-50μm
Fiber Height: -100~+50μm
Angle: 8.00+/-0.50° (APC)
Highlight:

12 Connectors Polishing Fixture

,

Hardened Stainless Steel S136 Fiber Optic Polishing Jig

,

3D Pass Rate 100% Fiber Polishing Holder
Basic Infomation
Place of Origin: Guangdong, China
Brand Name: chuanglixun
Model Number: SC/PC
Payment & Shipping Terms
Product Description
Efficient Fiber Optic 12 Connectors SC PC Polishing Fixture
This high-performance fiber polishing fixture/jig delivers exceptional stability and surface quality for optical fiber patch cord production. Manufactured from hardened stainless steel S136 for extended service life, this fixture is designed for SC PC (UPC) connector polishing and can be customized for FC, ST, LC, and other connector types.
Key Features
  • Specifically designed for SC PC (UPC) connector polishing
  • High efficiency - polishes 12 connectors in a single cycle
  • Replaceable holders for cost-effective polishing operations
  • IPC structure with independent compression for each connector
  • Exceptional performance: APC return loss ≥60dB, UPC return loss ≥55dB, insertion loss ≤0.20dB (typical)
  • 100% first-pass yield for end face quality
