Product Description
Single Mode cable is a single stand (most applications use 2 fibers) of glass fiber with a diameter of 8.3 to 10 microns that has one mode of transmission. Single Mode Fiber with a relatively narrow diameter, through which only one mode will propagate typically 1310 or 1550nm. Carries higher bandwidth than multimode fiber, but requires a light source with a narrow spectral width. Synonyms mono-mode optical fiber, single-mode fiber, single-mode optical waveguide, uni-mode fiber.
Technical Parameters
| Cable Type | Fiber Count | Cable Diameter(mm) | Cable Weight(kg/km) | Tensile Strength | Crush Resistance | Bending Radius |
| Long/Short Term | Long/Short Term | Static/Dynamic | ||||
| N | N/100mm | mm | ||||
| GYXTW-2~12 | 2~12 | 7.8 | 85 | 600/1500 | 300/1000 | 10D/20D |
| GYXTW-2~12 | 2~12 | 8 | 85 | 1000/3000 | 1000/3000 | 10D/20D |
| GYXTW-14~24 | 14~24 | 8.5 | 92 | 1000/3000 | 1000/3000 | 10D/20D |
Feature
- Good mechanical and temperature performance
- High strength loose tube that is hydrolysis resistant
- Special tube filling compound ensure a critical protection of fiber
- Crush resistance and flexibility
- PSP enhancing moisture-proof
- Two parallel steel wires ensure tensile strength
- Small diameter,light weight and friendly installation
- Long delivery length
Standards
GYXTW cable complies with Standard YD/T 769-2003
Storage/Operating Temperature
-40℃ to +70℃
Packing&Shipping
| LCL Delivery | <10000m | <20000m | <50000m | >100000m |
| 25 Days | 22 Days | 18 Days | Negotiable |
